Use this chart determine which Capatronics chip inductor family provides the value you need. Follow these tips to select the best overall combination of low cost, close tolerance, and high self resonant frequency.

Try 0602C, 0805C, 1008C or 1206C first
These series offer the best overall combination of low cost, close tolerance, and high self resonant frequency.

High Frequency Application
Any of our series ending in C use a ceramic core. They have the highest self resonant frequencies in the industry. And they're free from the batch-to-batch variations in industance, SRF and Q that are typical of ferrite inductors.

Close Tolerance Applications
Because of their ceramic coilforms, we are produce 0805C, 1008C and 1206C inductors to 1% or 2% tolerance very economically. This can eliminate the need for variable components in tuned circuits and oscillators.

Highest Possible Q
All our ceramic chip inductors provides exceptionally high Q. Among our ceramic chip inductors, the 0805HQ series offer the highest Q factors. For even higher ratings consider our air wound "Springs" These give you all the convenience of a surface mount part, plus Q values of up to 200 at 1.8 GHZ and inductance as low as 2%.

Custom Values
With our engineering and manufacturing facilities, we're able to quickly provide parts tailored to your needs. Technical Assistance, Fax : 00-603-77810855

HOW TO ORDER

SMT Wire Wound Inductor:
